Json Transformation Using Spark And Azure¶

In this article, I'll guide you on how to retrieve JSON data from an online API using Spark and Hadoop tools. We'll learn to split the data and save it in a 'silver' level. Then, we'll take the data from 'silver', partition it again, and store it in a *'gold'* level as Parquet files. This process is in line with the lakehouse architecture standards too.

Prerequisites¶

You'll need the following:

Azure Subscription: For using Azure services.
Azure Data Lake Storage Gen2: Two contaienrs, silver and gold inside a storage account.
Python with Pyspark : To develop and test this code a simple pyspark environment will do.
Hadoop ADLS Jars: You need to download the jars using tools like wget and store it and then refrence it in spark configuration. To know more refer to my article.

Script Breakdown¶

Initialize Spark Session¶

The script starts by creating a spark session by passing the downloaded hadoop jars for ADLS. The authentication method used is OAuth with service princiapl. Note, the registered app should have storage blob contributor role at the storage account level(preferred) or individually for silver and bronze. See appendix below.

# Author: Das, Purpose: Fetch and Partition Jsons
from pyspark.sql import SparkSession
import requests

# Note: Chek your actual client ID, tenant ID, and client secret value. Your's will be diffferent
storage_account_name = "TheStorageAccountNameHoldingSilverAndGoldContainers"
regapp_client_id = "Registered App's Client_ID"
regapp_directory_id = "Registered App's Directory ID"
regapp_client_secret = "Registered App's Client Secret Value"

# Initialize Spark session with Azure Data Lake Storage Gen2 configurations for OAuth Authentication using service princiapl
spark = SparkSession.builder \
    .appName("ADLS Access") \
    .config("spark.jars",
             "/usr/local/lib/python3.8/dist-packages/pyspark/jars/hadoop-azure-3.3.3.jar,"\
             "/usr/local/lib/python3.8/dist-packages/pyspark/jars/hadoop-azure-datalake-3.3.3.jar,"\
             "/usr/local/lib/python3.8/dist-packages/pyspark/jars/hadoop-common-3.3.3.jar") \
    .config(f"fs.azure.account.auth.type.{storage_account_name}.dfs.core.windows.net", "OAuth") \
    .config(f"fs.azure.account.oauth.provider.type.{storage_account_name}.dfs.core.windows.net", "org.apache.hadoop.fs.azurebfs.oauth2.ClientCredsTokenProvider") \
    .config(f"fs.azure.account.oauth2.client.id.{storage_account_name}.dfs.core.windows.net", regapp_client_id) \
    .config(f"fs.azure.account.oauth2.client.secret.{storage_account_name}.dfs.core.windows.net", regapp_client_secret) \
    .config(f"fs.azure.account.oauth2.client.endpoint.{storage_account_name}.dfs.core.windows.net", f"https://login.microsoftonline.com/{regapp_directory_id}/oauth2/token") \
    .getOrCreate()

Fetch and Load JSON Data¶

The next snippet fetches JSON data from a web API using the requests library and loads it into a DataFrame:

import requests

# URL of the JSON data source
json_url = 'https://data.ct.gov/resource/5mzw-sjtu.json'
response = requests.get(json_url)
json_data = response.json()

# Convert JSON to a DataFrame
df = spark.createDataFrame(json_data)

Define Paths and Partition Data¶

It's crucial to define the storage paths for 'silver' and 'gold' layers. Here's how the script partitions data:

# Define base paths for silver and gold storage layers
silver_path = f"abfss://{storage_account_name}.dfs.core.windows.net/silver"
gold_path = f"abfss://{storage_account_name}.dfs.core.windows.net/gold"

# Example column to partition the data by
partition_column = 'date_column'

# Write the data to the silver layer, partitioned by 'partition_column'
df.write.partitionBy(partition_column).mode("overwrite").json(silver_path)

# Read and rename the partition column for clarity
df_silver = spark.read.json(silver_path).withColumnRenamed(partition_column, "date_partition")

# Write the transformed data to the gold layer as Parquet
df_silver.write.partitionBy("date_partition").mode("overwrite").parquet(gold_path)

Stop Spark Session¶

Once all operations are complete, terminate the Spark session:

spark.stop()

Appendix¶

Reason for Partitioning¶

Partitioning is crucial when dealing with large datasets. It helps in breaking the data into smaller, more manageable pieces, which can be processed faster and more efficiently. In this script, I have partitoned the data by date_column. However, you can partiton it further by other criteria.

Register App and Assign Blob Contributor Role¶

Follow these merged steps to register your app in Azure AD and give it access to the silver and gold containers:

Go to Azure Portal → Azure Active Directory → App registrations, and create a new registration. Note your Application (client) ID and Directory (tenant) ID.
Within the app, navigate to Certificates & secrets to generate a new client secret. Remember to save the client secret value securely.
In your Azure Storage account, under Access Control (IAM), add a role assignment. Select "Storage Blob Data Contributor" and assign it to your registered app using the Application (client) ID.

The complete script¶

You can use this script directly in a jupyter notebook or create a function with it. For higher loads the script can be run in spark cluster.

from pyspark.sql import SparkSession
import requests

# Note: Chek your actual client ID, tenant ID, and client secret value. Your's will be diffferent
storage_account_name = "<input yours here>"
regapp_client_id = "<input yours here>"
regapp_directory_id = "<input yours here>"
regapp_client_secret = "<input yours here>"

# Initialize Spark session with Azure Data Lake Storage Gen2 configurations for OAuth Authentication using service princiapl
spark = SparkSession.builder \
    .appName("ADLS Access") \
    .config("spark.jars",
             "/usr/local/lib/python3.8/dist-packages/pyspark/jars/hadoop-azure-3.3.3.jar,"\
             "/usr/local/lib/python3.8/dist-packages/pyspark/jars/hadoop-azure-datalake-3.3.3.jar,"\
             "/usr/local/lib/python3.8/dist-packages/pyspark/jars/hadoop-common-3.3.3.jar") \
    .config(f"fs.azure.account.auth.type.{storage_account_name}.dfs.core.windows.net", "OAuth") \
    .config(f"fs.azure.account.oauth.provider.type.{storage_account_name}.dfs.core.windows.net", "org.apache.hadoop.fs.azurebfs.oauth2.ClientCredsTokenProvider") \
    .config(f"fs.azure.account.oauth2.client.id.{storage_account_name}.dfs.core.windows.net", regapp_client_id) \
    .config(f"fs.azure.account.oauth2.client.secret.{storage_account_name}.dfs.core.windows.net", regapp_client_secret) \
    .config(f"fs.azure.account.oauth2.client.endpoint.{storage_account_name}.dfs.core.windows.net", f"https://login.microsoftonline.com/{regapp_directory_id}/oauth2/token") \
    .getOrCreate()

# Azure Storage configuration
silver_container_name = "silver"
gold_container_name = "gold"

# Download JSON data from the web
json_url = 'https://data.ct.gov/resource/5mzw-sjtu.json'
response = requests.get(json_url)
json_data = response.json()
# Assuming json_data is a list of dictionaries (records)
# Create a DataFrame from the JSON data
df = spark.createDataFrame(json_data)

# Define the base path for silver and gold containers
base_silver_path = f"abfss://{silver_container_name}@{storage_account_name}.dfs.core.windows.net/"
base_gold_path = f"abfss://{gold_container_name}@{storage_account_name}.dfs.core.windows.net/"

# Add the relative path and partition the data by the 'date_column'
# Replace 'date_column' with the actual column name you want to partition on
partition_column = 'daterecorded'  # Example partition column. You can choose another column in your case.
silver_path = f"{base_silver_path}data/"
gold_path = f"{base_gold_path}data/"

# Write JSON data to the silver container, partitioned by 'date_column'
df.write.partitionBy(partition_column).mode("overwrite").json(silver_path)

# Read the JSON file back into a DataFrame, it will recognize partitions automatically
df_silver = spark.read.json(f"{silver_path}").withColumnRenamed("daterecorded", "date_partition")

# Write the DataFrame to the gold container as a Parquet file, also partitioned
df_silver.write.partitionBy("date_partition").mode("overwrite").parquet(gold_path)

# Stop the Spark session
spark.stop()

Conclusion¶

This is a versatile script that can be executed directly in a Jupyter notebook or encapsulated within a function for convenience. With minor configuration tweaks it can be run in a spark cluster to handle larger workloads. Note: with this script you might see warnings like *Warning: Ignoring non-Spark config property: fs.azure.account.oauth.provider.type.strgacweatherapp.dfs.core.windows.net*
